This is a highly popular, high-performance analog mini servo. Built with surface-mount technology (SMT), it is prized for delivering full-sized torque and speed in a significantly smaller and lighter footprint.
Technical Specification
Parameter Specification
Signal Type Analog (PWM)
Motor Type 3-Pole Ferrite / Cored Metal Brush
Gear Material Heavy-Duty Metal (1x Metal-Plastic hybrid, 3x Metal)
Output Spline 24-Tooth (Hitec Standard / C1 Spline)
Bearing Type Single Top Ball Bearing
Operating Voltage 4.8V to 6.0V DC Max
Torque (at 4.8V) 3.9 kg-cm / 54.0 oz-in
Torque (at 6.0V) 4.8 kg-cm / 67.0 oz-in
Speed (at 4.8V) 0.14 sec / 60°
Speed (at 6.0V) 0.11 sec / 60°
Dimensions 32.4 mm × 16.8 mm × 31.0 mm
Weight 31.0 g / 1.09 oz
